HD12DB

Down-Mixing DAC 2-Way HDMI Split

Available Colours
Black matt
  • Down Mixing DAC 2-Way HDMI Splitter
  • Video scaling up to 4K 60Hz 4:4:4
  • Converts 5.1ch Dolby or DTS Audio
  • Stereo 2ch out: HDMI/Optical/Analog
  • 1x HDMI input: 4K UHD @ 60Hz 4:4:4
  • HDMI output 1: loop out
  • HDMI output 2: scaled output
  • HDCP 2.2 with advanced EDID
  • RRP: $699.00

CLEARANCE ITEM

WAS $454.00 INC GST

NOW $363.00 INC GST

LIMITED STOCK AVAILABLE

The Blustream HD12DB has been designed to convert and downmix embedded 5.1ch Dolby Audio or DTS Audio within a HDMI signal into a stereo 2ch signal available on HDMI, optical and analogue audio outputs.

The HD12DB features a HDMI loop out to pass the original video and multi-channel embedded audio signal to compatible equipment, with a second HDMI output featuring video scaling of resolutions up to 4K 60Hz 4:4:4 video to various lower video formats.

This provides the perfect cost effective solution for ensuring that 4K UHD video and multi-channel audio can be distributed around a multi-room system where there are a mixture of 2ch and 5.1ch zones with multiple output resolution requirements.

• Features an in-built DAC (Digital to Analogue audio Converter) that converts 5.1ch Dolby Audio or DTS Audio to a stereo 2ch signal available on HDMI, optical and analogue audio outputs concurrently
• Supports the following audio input formats: Dolby 5.1, DTS-ES 6.1, DD+5.1, DD+2.0, PCM 5.1, PCM 2.0*
• Features 1 x HDMI input supporting 4K UHD video (4K 60Hz 4:4:4) that is replicated to 2x HDMI outputs
• HDMI loop out will replicate the HDMI input signal up to 4K 60Hz 4:4:4 and 5.1ch Dolby Audio & DTS Audio
• HDMI output 2 features a video scaler allowing the output resolution to be set to the following formats:
- 3840x2160@60Hz
- 3840x2160@50Hz
- 3840x2160@30Hz
- 3840x2160@25Hz
- 4K DCI@25Hz 4:4:4
- 4K DCI@30Hz 4:4:4
- 4K DCI@50Hz 4:4:4
- 4K DCI@60Hz 4:4:4
- 1920x1080@60Hz
- 1920x1080@50Hz
- 1280x720@60Hz
- 1280x720@50Hz
- 1920x1200@60Hz
- 1680x1050@60Hz
- 1024x768@60Hz
• HDMI audio breakout to down-mixed analogue L/R audio and down-mixed optical digital outputs concurrently
• HDCP 2.2 compliant with advanced EDID management

*Please Note: this product does not support decoding of DTS CD bitstreams. Playback of this format may produce undesirable noise.
