C66

6x6 HDBaseT Matrix Switcher

Available Colours
Black matt
  • 6x6 HDBaseT Matrix - 70m
  • Supports 4K UHD up to 40m
  • Inputs: 6 x HDMI
  • Outputs: 6 x HDBaseT
  • Bi-directional IR on all outputs
  • Control: front, IR, RS-232, TCP/IP
  • Supports PoC (Power over Cable)
  • HDCP2.2 compliant
  • RRP: $3,399.00

CLEARANCE ITEM

WAS $2,209.00 INC GST

NOW $1,767.00 INC GST

LIMITED STOCK AVAILABLE

The Blustream Contractor 6x6 HDBaseT™ Matrix offers unprecedented performance and value for the custom installation market. The C66 is a 4K HDCP 2.2 Matrix delivering HDMI, bi-directional IR, and PoC (Power over Cable) up to lengths of 70m over a single CAT cable. The Matrix also provides advanced features including simultaneous HDBaseT™ / HDMI on output 1 and a web browser interface module for control and configuration of the Matrix.

  • Advanced HDBaseT™ technology offering uncompressed video and audio with zero latency
  • Features 6 x HDMI inputs which can be independently routed to 6 x HDBaseT™ outputs
  • Output 1 features simultaneous HDMI and HDBaseT™ output
  • Extends HDMI up to a distance of 70m over single CAT cable
  • Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports 3D signal display
  • Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio Transmission
  • Web interface module for control and configuration of the Matrix
  • Supports bi-directional IR on all HDBaseT™ outputs
  • Supplied with Blustream IR receivers and emitters
  • Control via front panel, IR, RS-232 and TCP/IP
  • Supports PoC (Power over Cable) to power compatible HDBaseT™ receivers
  • 3rd party drivers available for major control brands
  • Advanced EDID management
  • HDCP 2.2 compliant
